These brushless motors with neodymium magnets and a rotating case are manufactured using the latest technology from the finest quality materials. The hardened steel shaft supported by three ball bearings, and overall robust yet lightweight construction, ensure a long service life. A new feature in the AXI design is a provision for radial mounting (see picture). The optional radial mount set includes: mounting flange, propeller adaptor, securing collar, and screws. The unique design of these motors gives extremely high torque levels to turn large diameter and high pitch propellers with a high level of efficiency. This motor is suitable for large sailplanes weighing up to 6000g and sports aerobatic models up to 4500g.
| | Specification | | No. of cells | 16 - 24
5 - 8 Li-Poly | | RPM/V | 385 RMP/V | | Max. efficiency | 88% | | Max. efficiency current | 18 - 40 A (>84%) | | No load current / 10 V | 1,3 A | | Current capacity | 60 A/60 s | | Internal Resistance | 63 mohm | | Dimensions (diameter. x lenght) | 49,8x65,5 mm | | Shaft diameter | 6 mm | | Weight with cables | 409 g |
|
