SpecificationsStator Diameter | 40.0 mm (1.575 in) | Stator Thickness | 35.0 mm (1.024 in) | No. of Stator Arms | 12 | Magnet Poles | 10 | Motor Wind | 12 Turn Delta | Motor Wire | 22-Strand 0.25mm | Motor Kv | 380 RPM / Volt | No-Load Current (Io) @ 10 v | 1.52 Amps | Motor Resistance (Rm) | 0.025 Ohms | Max Continuous Current | 70 Amps | Max Continuous Power | 2600 Watts | Weight | 435 Grams (15.34 oz) | Outside Diameter | 48.8 mm (1.921 in) | Shaft Diameter | 7.98 mm (0.30 in) |
|
|
