89" Slick
The 89 Slick, designed by Andrew Jesky, is one of the largest 50CC aircraft in the world, and is remarkably light for its huge size. Larger than some 35% aircraft, the Slick delivers huge performance very similar in feel to a 40% aircraft. Pilots all over the USA love the anti-gravity 3D performance of their Slick, and appreciate the extreme precision of the AJ-designed aerodynamic package. This is the aircraft that will show your best piloting off to the world and make it all easy for you.
The 89 Slick features all important performance and durability features: 4-40 ball link hardware, pre-finished canopy and hatch, pre-finished motor box with aluminum bracing, carbon one-piece landing gear with aluminum-braced mount, pre-hinged wings and stabs, carbon wing and stab tubes, carbon wing and stab receiver tubes, carbon tailwheel, aluminum-hub wheels, genuine ultracote, wing bags, and stab bag.
Note: The 89" Slick firewall is set up for the DA-50 engine. This engine provides excellent performance and bolts on with stock 3" standoffs.
The DA-60 provides extreme performance with no weight penalty and is recommended. The DA-60 is NOT the same length as the DA-50 and does not mount the same way.
The 89" kit includes a generic fuel tank, but American-made Fourtitude fuel tanks are the best and are a recommended upgrade.
Electric Power System:
Hacker Q80-8M Motor - 24 x 10 prop
Castle Creations ICE HV160 ESC
12S 5000mah Lipo (Two 6S 5000mah running in series)
Servos:
QTY 5 Hitec HS-7955TG
Servo Arms:
QTY 1 SWB 4" Offset for Rudder
QTY 2 SWB 2" Single Sided for Elevators
QTY 2 SWB 1.5" Single Sided for Ailerons
Extensions:
QTY 2 52" For Elevators
QTY 2 20" For Ailerons
QTY 2 8" For Ailerons (Rx side)
QTY 1 20" For Throttle or ESC
QTY 1 12" For Rudder
