性能:(Performance)
8.5HP/7500rpm (8.5HP/7500rpm)
怠速:1500 rpm/分鐘(Idle Speed:1500 rpm/min.)
拉力21Kg/海拔100米(21Kg Static Thrust / 100 meters Altitude)
拉力18Kg/海拔1800米(18Kg Static Thrust / 1800 meters Altitude)
適用螺旋槳規格:25×10;26×9;27×8;
(The specification of the aircraft propeller: 25×10;26×9;27×8;
適用火星塞型號(the type of the sparking plug ):NGK CM6
參數:(Parameter)
排量( Exhaust Amount ) : 85cm3
缸徑×行程( diameter × stroke ) : 52mm×40mm
壓縮比(Ratio of compression) : 9.5:1
潤滑比(Ratio of lubricating capacity) : 30:1
重量: 主機1930克+排氣管250克+點火器130克
Weight: Main engine -1930g Exhaust pipe - 250g
Ignition equipment - 130g
3、點火器工作電壓(Ignition volt):4.8V-8.4V
連絡方式:0912-278833蔡先生 |
