規格如下:
NextGeneration type
next 10.36-12
Weight about 830 g
850 g
Size (w / d / h) about 160*180*67 mm
Colour of the case anthracite
Internal fan 12 V / 7 W /
55 dBa
Serial port (included) 5 V SIO
Optional available in-/outputs included
USB + temperature sensor + blinking light + fan
Supply voltage range 10.0 - 15.0 V
Under voltage warning 11.6 - 10.4 V
- adjusting range
Under voltage warning 0.5 V
- cut off below warning
Supply current up to (about) 25 A
Quiescent current about ... 100 mA
+ current LCD-illumin. (disconnectable, about) 50 mA
Trickle charge currents Ni-Cd Trickle pulses
Trickle charge currents other battery types no
Adjustable Lithium voltages yes
(for full / empty)
Password protected owners name yes
User setted charge/discharge configurations yes
Battery 1 Output - Charge circuit next 10.36-8
Number of voltage measuring inputs 8
Ni-Cd / Ni-MH-batteries
cell-count @ 1.65V 1*-36 cells
(Nickel-cell)
max. battery capacity Ni-Cd 0.1 - 5.0 Ah
max. battery capacity Ni-MH 0.1 - 10.0 Ah
Lead / Li-Fe / Li-Io / Li-Po batteries
Number of balancing inputs/outputs 8
12
Max. balancing current 1:00 AM
Number of Li-Po cells 14 cells
Number of Li-Io cells 14 cells
Number of Li-Fe cells 16 cells
Number of Lead cells 23 cells
Max. battery capacity in mAh 0.1 - unlimited
Charge power next 10.36-8
@ charge voltages
next 10.36-12
Charge power @ 12V 240 W
car battery voltage about
Charge current @ 1-24V 10.0 A
(~1-15 Ni-/~1-6Li-cells) about
Charge current @ 30V 8.0 A
(~18 Ni-/~7 Li-cells) about
Charge current @ 40V 6.0 A
(~24 Ni-/~9 Li-cells) about
Charge current @ 45V 5.3 A
(~27 Ni-/~11 Li-cells) about
Charge current @ 50V 4.8 A
(~30 Ni-/~12-Li-cells) about
Charge current @ 60V 4.0 A
(~36 Ni-/~14 Li-cells) about
Battery 1 output next 10.36-8
- discharge circuit
next 10.36-12
Cell count (@ 1.30 V/Ni- / 1-40 Ni-cells
4,00 V/Li-cell) 1-14 Li-cells
Discharge power about 240 W
@ 12 V car battery voltage
Discharge current @ 1-24 V 10.0 A
(~1-18 Ni-/~1-6 Li-cells) about
Discharge current @ 32 V 7.5 A
(~24 Ni-/~8 Li-cells) about
Discharge current @ 36 V 6.7 A
(~27 Ni-/9 Li-cells) about
Discharge current @ 40 V 6.0 A
(~30 Ni-/~10 Li-cells) about
Discharge current @ 49 V 4.9 A
(~36 Ni-/~12 Li-cells) about
Discharge current @ 54 V 4.4 A
(~40 Ni-/~14 Li-cells) about
Max. discharge power when connected to a fully charged car battery or to an AC/DC power supply 100 W
Battery 2 output - charge circuit
next 10.36-12
Ni-Cd / Ni-MH batteries
cell count (@ 1.65V / cell) 1*-6 cells
Charge current ~ 0.1 - 5 A
Charge power @ 13,8 V car batt. & 12V output 2 about 60 W
Max. battery capacity Ni-Cd 0.1 - 2.5 Ah
Max. battery capacity Ni-MH 0.1 - 5.0 Ah
Lead / Li-Fe / Li-Io / Li-Po batteries
Number of balancing inputs/outputs 0
Li-Po cell count 1 - 2/3**cells
Li-Io cell count 1 - 2/3**cells
Li-Fe cell count 1 - 3 cells
Lead cell count 1 - 4/5** cells
Max. capacity mAh 0.1 - unlimited
